Spotting Machine

spotting machine

A spotting machine, in the context of the textile and garment industry, is a specialized piece of equipment used for the removal of localized stains and blemishes on fabrics. Also known as a spot-cleaning machine, it is employed in dry cleaning establishments and textile processing facilities to treat individual spots or stains on garments. The spotting machine typically consists of a spotting board, an air gun, and various cleaning agents or solvents. The operator manually identifies and targets specific stains, applying the appropriate cleaning solution and using the air gun to remove the stain through a combination of suction and steam. The spotting machine plays a crucial role in the garment care process, enhancing the overall quality and appearance of clothing items by effectively addressing localized imperfections before or after the primary cleaning process.

Specifications:-

  • With & Without air compressor
  • Three cold spotting Gun
  • One air/ steam heat proof gun
  • Fully S.S
  • Movable side arms for small suction
  • 3 Phase motor & high suction
ModelWork Table Size (LxWxH)SUCTION ARM SIZE (LXWXH)NO. OF CHEMICAL GUNSSUCTION MOTOR HPCOMPRESSOR MOTOR HPOVERALL SIZE (LXWXHNET WIGHT kgs
SJTMSM700x330x60400x130x302+10.7521400x600x1600260
SJTMSM460X160X40NA2+17.75NA910x410x1600110
